PCT14ST - Cordless Combi Tool

Article Number: 159.000.233

Model: PCT14ST

Brand: Holmatro

Basic Specifications:

• Max. working pressure: 10.443 psi (720 / 72 bar/Mpa)
• Battery included: no
• Connectivity, mobile app: Bluetooth

Performance:

• Spreading distance: 362 mm (14.3 in)
• Max. cutting opening: 277 mm (10.9 in)
• Max. spreading force: 303.492 lbf (1350 / 137.7 kN/t)
• Min. spreading force (EN 13204): 7.419 lbf (33 / 3.4 kN/t)
• Theoretical cutting force: 60.249 lbf (268 / 27.3 kN/t)
• Max. squeezing force: 7.644 lbf (34 / 3.5 kN/t)
• Min. squeezing force (EN 13204 2025 Ed.): 16.6 kN (1.7 t, 3.732 lbf, 16.6 / 1.7 kN/t)
• Protection rate: IP57
• Sound emission @ 1m/3.25ft: 76 dB(A)
• Sound emission @ 4m/13ft: 67 dB(A)
• Vibration level: <2.5 m/s²
• Directives: 2006/42/EC, 2014/30/EU, 2014/53/EU

General Specifications:

• Hydraulic safety factor: 2:1
• Endurance test tool: 1000 cycles of spreading while the tool is loaded and 1000 cycles of biting in material that cannot be cut
• Endurance test dead man's handle: 6000 cycles
• EN 13204 compliant: yes
• EN 13204 classification: BK33/362E-14.2
• EN 13204, cutting capacity: 1E 2E 3E 4E 5E
• NFPA 1960 compliant: yes
• NFPA 1960, cutting capacity: A5 B5 C5 D6 E4 F3
• NFPA 1960, HSF: 40 kN (4.1 t, 8.992 lbf, 40 / 4.1 kN/t)
• NFPA 1960, LSF: 30 kN (3.1 t, 6.744 lbf, 30 / 3.1 kN/t)
• Cutting performance round bar (S235 acc. to EN 13204): 24 mm (0.9 in)

Dimensions, Weight and Temperature:

• Weight, ready for use: 14.2 kg (31.3 lb)
• Weight (excl. battery): 12.6 kg (27.8 lb)
• Temperature range: -20 +55 °C (-4 +131 °F)
• Dimensions (AxBxC): 731 x 270 x 275 mm (28.8 x 10.6 x 10.8 in)

Product Description: Cordless Combi Tool, part of the Holmatro Pentheon Series. Designed to offer you unrivaled performance, superior usability, advanced connectivity and exceptional serviceability. This multifunctional tool can be used for cutting, spreading and squeezing and is therefore suitable for a variety of applications, ranging from forcible entry to extrication of persons trapped.

Features & Benefits:

• Unparalleled speed for faster ST operations: Fastest combi tool on the market thanks to Stepless Speed Maximization (patented) – The tool continuously optimizes its motor and pump settings, giving you maximum speed at any tool load; Maximum operating flexibility with two operation modes – Reduced speed training/demo mode and high speed Pentheon mode
• Ultimate speed control for more controlled tool handling: Two-speed inline control handle – Switch between high-speed and low-speed and keep perfect control at all times
• Guaranteed maximum power during a tool’s entire lifespan: Electronic motor control and pressure monitoring – Constant lifetime performance for every Pentheon tool
• Minimum sound level for maximum stealth properties: Automatic engine start and stop – If the tool is switched on, the engine will start when you turn the control handle, and stops when you release the handle
• Battery management made easy: Charge batteries directly on the tools with the On-Tool Charging System; Priority charging for on-tool batteries over batteries on a separate charger; Charge up to six batteries automatically – Connect up to three chargers to one single outlet; Holmatro battery – Power Pentheon tools as well as OmniLock struts (patented) and other upcoming Holmatro products
• Superb ergonomics for effortless handling: Easy tool operation – Inline control handle with 360° access; Hold every tool in any position – 360° carrying handle made of tough, damage-proof material
• Continue your mission under all conditions: Flawless performance under water, at high and low outdoor temperatures and in rain and snow; Easier communication during ST operations – A new and improved drive system ensures tool operation at a lower sound level; Automatic LED lights in the carrying handle, powered by the main battery. The lights can also be operated manually
• Realtime tool insights to adapt and change tactics: Connect every tool to your tablet or phone with Bluetooth®; Easy to use and intuitive MyHolmatro app; Real-time diagnostics during every operation – Monitor battery state of health and state of charge, pump stage, motor temperature, working pressure (including peak pressure) and speed mode
• Automatically keep your tools in perfect condition: Quickly and easily perform an automated Pentheon Self Check with the MyHolmatro app – Automatically check the drive system, speed and pressure, battery firmware and battery state of health
• Effortless tool maintenance: Premium tool service thanks to the Holmatro Inspection Procedures (HIP) – An extensive software program for Authorized Holmatro (Dealer) Service Technicians
